k8s親和性調度-nodeAffinity

發布時間：2023-07-02 23:58:23 作者：網友整理

簡介

nodeAffinity就是節點親和性，相對應的是Anti-Affinity，就是反親和性。

這種方法比nodeSelector靈活，可以有一些簡單的邏輯組合。

調度可以分成軟策略和硬策略兩種方式：

軟策略就是如果你沒有滿足調度要求的節點的話，POD 就會忽略這條規則，繼續完成調度過程。
沒有滿足條件的節點的話，就不斷重試直到滿足條件為止。

例子

apiVersion: Apps/v1
kind: Deployment
metadata:
  labels:
    app: hostname
  name: hostname
  namespace: default
spec:
  progressDeadlineSeconds: 600
  replicas: 2
  revisionHistoryLimit: 10
  selector:
    matchLabels:
      app: hostname
  strategy:
    rollingUpdate:
      maxSurge: 10%
      maxUnavailable: 1
    type: RollingUpdate
  template:
    metadata:
      creationTimestamp: null
      labels:
        app: hostname
    spec:
      affinity:
        nodeAffinity:
          requiredDuringSchedulingIgnoredDuringExecution:
            nodeSelectorTerms:
            - matchExpressions:
              - key: kube.NETes.io/hostname
                operator: In
                values:
                - k8s-node.example.com
                - centos7.example.com
          preferredDuringSchedulingIgnoredDuringExecution:
          - weight: 1
            preference:
              matchExpressions:
              - key: node-type
                operator: In
                values:
                - testing
      containers:
      - image: tosomeone/hostname:v1.0.3
        imagePullPolicy: IfNotPresent
        resources:
          requests:
            memory: 20Mi
            cpu: 100m
          limits:
            memory: 30Mi
            cpu: 150m
        livenessProbe:
          failureThreshold: 5
          httpGet:
            path: /
            port: 8080
            scheme: HTTP
          initialDelaySeconds: 1
          periodSeconds: 2
          successThreshold: 1
          timeoutSeconds: 2
        name: hostname
        ports:
        - containerPort: 8080
          protocol: TCP
        readinessProbe:
          failureThreshold: 3
          httpGet:
            path: /
            port: 8080
            scheme: HTTP
          initialDelaySeconds: 2
          periodSeconds: 1
          successThreshold: 1
          timeoutSeconds: 5
        lifecycle:
          postStart:
            exec:
              command:
                - echo
                - "started"
          preStop:
            exec:
              command:
                - sleep
                - "3"
        terminationMessagePath: /dev/termination-log
        terminationMessagePolicy: File
      DNSPolicy: ClusterFirst
      restartPolicy: Always
      schedulerName: default-scheduler
      securityContext: {}
      terminationGracePeriodSeconds: 30

preferredDuringSchedulingIgnoredDuringExecution：指定的就是軟策略

requiredDuringSchedulingIgnoredDuringExecution：指定的就是硬策略

例子中優先選擇node上有node-type=testing標簽的node，且這些node需要滿足主機名k8s-node.example.com或者centos7.example.com

操作符有下面的幾種：
